Battery Type:
Lithium ion phosphate Battery
Brand:
GSL ENERGY
Model No:
GSL-KS40
Battery combination:
4S 13P 26650 3.2V 3200mAh
Rated voltage:
12.8
Capacity:
40Ah
Size ( mm) / Size ( inch) L*W*H:
197*165*169/ 7.8*6.5*6.7
Weight:
4.5 kgs/ 9.92 lbs
Application:
AGV, Robots, Solar UPS, Solar street led lights, golf carts, Marine UPS.
Package:
UNCarton
Payment terms:
T/T
Delivery time:
With 20 days after deposit
Inquiry
Enterprise Strength
  • GSL ENERGY has a comprehensive service system covering from pre-sales to after-sales. We are able to provide one-stop and thoughtful services for consumers.
Company Advantages
1. The electrode materials of GSL ENERGY 12v 50ah lithium battery are strictly handled to be free of contamination, physical damage, and burrs. Because these substances can cause penetration of the separator.
2. The 12v 20ah lithium battery experiments indicate that 12v 50ah lithium battery is deep cycle rv battery under complex conditions.
3. The product can easily and conveniently be recharged with a simple battery charger, which is very convenient for people.
4. The product can work for up to 20+ years while surviving thousands of recharge cycles and operating across a wide temperature range.
PRODUCT PARAMETER
GSL ENERGY


Products typeMODEL : KS40Battery pack Discharge Current (Max.)80A
Cell TechnologyLifepo4Efficiency98%
Battery Pack Capacity (Wh)512Depth of Discharge100%
Battery pack Voltage (Vdc)12.8Dimension (L*W*H, mm)197*165*169
Battery pack Capacity (AH)40CommunicationOption of CANBUS OR RS485, SMbus
Battery pack Cell Quantity in Series (pcs)4SProtection ClassIP54
Battery pack Charge Voltage (Vdc)14.6Weight4.5KG
Battery System Charge Current (Standard)10AOperation Life10+ years
Battery pack Charge Current (Normal)20AOperation Cycle LifeOver 4000 times
Battery pack Charge Current (Max.)40AOperation Temperature0-50℃
Battery pack Discharge lower-Voltage (Vdc)10VStorage Temperatureminus 20 -- 60 ℃
Battery System Discharge Current (Standard)20AProducts certificatesTÜV (IEC62619), CE
Battery pack Discharge Current (Normal)40ATransfer CertificatesUN38.3 , MSDS


PRODUCTS DISPLAY



GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4
GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-1


GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-2
GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-3


GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-4

12V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.


PRODUCT ADVANTAGE



GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-4

GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-5


1.High integrated with less installation space.

2.Long life cycle, >3000 times at 80% DOD.

3.Without heavy metals and environment friendly.

4.Maintenance free, no memory effect.

5.Internal BMS with full protection, high voltage protection with higher reliability.



APPLICATION


GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-6


Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.



PACKING

GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-7

Good Quality Packs
VS
GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-8

Low Quality Packs

SUPER SAFETY TEST



GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-9
GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-10
GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-11

Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.


WHY CHOOSE US



Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
Fresh battery-- All battery is fresh Production.


GSL ENERGY-High-quality Lithium Battery 12v 40ah | Long Life 12v 40ah Lifepo4-12




Company Features
1. GSL GROUP Limited specializes in producing 12v 50ah lithium battery of great fineness.
2. GSL GROUP Limited has always adopted world-class technology for production of lifepo4 battery 12v 100ah .
3. We embrace social responsibility in our products, the way we conduct our business, and in our relations with customers, employees, vendors, shareholders, and communities. We make sure that all our orders meet the highest standards and are delivered on time. This dedication has helped us maintain our reputation of delivering quality products within due time. No matter how big or small the project, we have always upheld our promise to customers. Contact us!
