GSL ENERGY lithium battery 12v 200ah free sample for cycles
Battery Type:
Lithium ion phosphate Battery
Brand:
GSL ENERGY
Model No:
GSL-KS20
Battery combination:
4S6P 26650 3.2V 3200mAh
Rated voltage:
12.8
Capacity:
20Ah
Size ( mm) / Size ( inch) L*W*H:
181*76*167/ 7.1*3.0*6.6
Weight:
2.5 kgs/ 6.28 lbs
Application:
AGV, Robots, Solar UPS, Solar street led lights, golf carts, Marine UPS.
Package:
UNCarton
Payment terms:
T/T , L/C
Delivery time:
With 20 days after deposit
Application Scope
Lithium Battery can be used in automobiles, motorcycles, tractors, diesel engines and other products.GSL ENERGY has been engaged in the production of Lithium Battery for many years and has accumulated rich industry experience. We have the ability to provide comprehensive and quality solutions according to actual situations and needs of different customers.
1. lithium battery 12v 200ah is produced with high craftwork.
2. The effective quality control addresses the product defects.
3. The product caters to market demand and will be more widely used in the market.
4. Products sell well in the global market, with broad market potential.
PRODUCT PARAMETER
GSL ENERGY
| Products type | MODEL : KS20 | Battery pack Discharge Current (Max.) | 40A |
| Cell Technology | Lifepo4 | Efficiency | 98% |
| Battery Pack Capacity (Wh) | 256 | Depth of Discharge | 100% |
| Battery pack Voltage (Vdc) | 12.8 | Dimension (L*W*H, mm) | 181*76*167 |
| Battery pack Capacity (AH) | 20 | Communication | Option of CANBUS OR RS485, SMbus |
| Battery pack Cell Quantity in Series (pcs) | 4S | Protection Class | IP54 |
| Battery pack Charge Voltage (Vdc) | 14.6 | Weight | 2.5KG |
| Battery System Charge Current (Standard) | 5A | Operation Life | 10+ years |
| Battery pack Charge Current (Normal) | 10A | Operation Cycle Life | Over 4000 times |
| Battery pack Charge Current (Max.) | 20A | Operation Temperature | 0-50℃ |
| Battery pack Discharge lower-Voltage (Vdc) | 10V | Storage Temperature | minus 20 -- 60 ℃ |
| Battery System Discharge Current (Standard) | 10A | Products certificates | TÜV (IEC62619), CE |
| Battery pack Discharge Current (Normal) | 20A | Transfer Certificates | UN38.3 , MSDS |
PRODUCTS DISPLAY
12V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.
PRODUCT ADVANTAGE
1.High integrated with less installation space.
2.Long life cycle, >3000 times at 80% DOD.
3.Without heavy metals and environment friendly.
4.Maintenance free, no memory effect.
5.Internal BMS with full protection, high voltage protection with higher reliability.
APPLICATION
Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
PACKING
Good Quality Packs
VS
Low Quality Packs
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
Company Features
1. GSL GROUP Limited is a high-tech company which mainly specializes in lithium battery 12v 200ah .
2. According to data from clients, our products have been widely used in different applications around the world. We have made more efforts in expanding the product ranges for more different application purposes.
3. In this booming society, GSL ENERGY aims to be a much better company in the area of lithium rv battery . Ask online! Our service team at GSL ENERGY will answer your questions promptly, efficiently and responsibly. Ask online!
