Good Quality Packs
Products type | MODEL : GSL48100 | Battery pack Discharge Current (Max.) | 250A |
Cell Technology | NCM Lithium | Efficiency | 98% |
Battery Pack Capacity (Wh) | 5120 | Depth of Discharge | 100% |
Battery pack Voltage (Vdc) | 51.2 | Dimension (L*W*H, mm) | 508*280*230 |
Battery pack Capacity (AH) | 100 | Communication | Option of CANBUS OR RS485, SMbus |
Battery pack Cell Quantity in Series (pcs) | 14S | Protection Class | IP54 |
Battery pack Charge Voltage (Vdc) | 58.4 | Weight | 48.5KG |
Battery System Charge Current (Standard) | 10A | Operation Life | 10+ years |
Battery pack Charge Current (Normal) | 20A | Operation Cycle Life | Over 4000 times |
Battery pack Charge Current (Max.) | 50A | Operation Temperature | 0-50℃ |
Battery pack Discharge lower-Voltage (Vdc) | 46V | Storage Temperature | minus 20 -- 60 ℃ |
Battery System Discharge Current (Standard) | 20A | Products certificates | TÜV (IEC62619), CE |
Battery pack Discharge Current (Normal) | 100A | Transfer Certificates | UN38.3 , MSDS |
PRODUCTS DISPLAY
48V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.
PRODUCT ADVANTAGE
1.High integrated with less installation space.
2.Long life cycle, >3000 times at 80% DOD.
3.Without heavy metals and environment friendly.
4.Maintenance free, no memory effect.
5.Internal BMS with full protection, high voltage protection with higher reliability.
APPLICATION
Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
PACKING
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
Electric Motor: 1000w, 36V, and lower Noise motor.
Maximum speed: 15km/h
Forward and backward with 2 speed shift
Maximum load: 150kg
Climbing capacity: 25 degree
Front and Rear wheel: 13inches tubeless tire.
The front and rear with excellent shock absorber
Foldable
Rear hydraulic brake
Transmission: steel chain drive
Battery: 36V 6pcs of 12V 20AH battery
Recharging time:8-10Hours
Driving time:5.5-6Hours after a full charge
Model No.: | LT-A2 | LT-A4 | LT-A4+2 | LT-A8 | LT-A8+3 |
Motor: | 48V/4KW | 48V/4KW | 48V/4KW | 48V/4KW | 48V/4KW |
Battery: | trojan ,8V*6 | trojan ,8V*6 | trojan ,8V*6 | trojan ,8V*6 | trojan ,8V*6 |
Transaxle: | 12.31:1 | 12.31:1 | 16:01 | 16:01 | 16:01 |
Overall Size: | 2390*1200*1900mm | 3070*1200*1900mm | 3400*1200*1900mm | 3778*1200*1900mm | 4120*1200*1900mm |
Ground clearance: | 110mm | 110mm | 110mm | 110mm | 110mm |
Tread distance: | front880/rear990mm | front880/rear990mm | front880/rear990mm | front880/rear990mm | front880/rear990mm |
Net weight: | 270kg | 290kg | 310kg | 370kg | 430kg |
Loading: | 2 people | 4 people | 6 people | 8 people | 11 people |
Forward speed: | 25km/h | 25km/h | 25km/h | 25km/h | 25km/h |
Braking dist: | 4.9m | 4.5m | 3.4m | 4.5m | 4.5m |
Turning radius: | 3.5m | 4.2m | 4.7m | 5.8m | 5.8m |
Climbing ability: | 0.3 | 0.25 | 0.2 | 0.18 | 0.15 |
Maximum mileage: | 100km | 100km | 100km | 80km | 80km |
Unique design * Considerate safety
Covered with "PP" automotive engineering materials, can withstand weighing 40 tons of truck rolling. Ultimate security,durable, anti-aging with beautiful appearance, long life cycle performance.
Convenient * Low power consumption
Large-capacity battery, energy saving, short charging time. Driving for 100 km with 5 hours' charge.
International standard quality * Advanced configuration
Imported Rear Axle technology, safer and more stable
Practical * Flexible
Multipurpose pedal, set parking, braking, acceleration function together as a whole, easy to operate
Innovative concept * Durable materials
Steel chassis, brackets, strong material, innovative electrophoresis soak on the material inside and outside, enhanced corrosion resistance ability
Innovative choice * Extreme durability
Independent suspension damping system,utilizing car steering system design to reduce changes in beam positioning, double-spring dispersion stress to reduce the sense of vibration, significantly enhance the ride comfort
Intelligent control * travel at heart
Apply imported controller, computer programming a variety of operating modes,in addition with electric brake and automatic anti-charging function
