Good Quality Packs
GSL ENERGY Brand mounted energy battery storage powerwall battery
Battery Type:
Lithium ion phosphate Battery
Brand:
GSL ENERGY
Model No:
GS5000
Rated voltage:
51.2
Capacity:
100Ah
Size ( mm) / Size ( inch) L*W*H:
650*480*190 / 25.6*18.9*7.5
Weight:
54kgs/ 119 lbs
Application:
Home ESS, Solar ESS, Solar off grid backup system, Solar Hybrid inverter UPS
Package:
Carton Box
Payment terms:
T/T
Delivery time:
With 25 days after deposit
Product Comparison
Lithium Battery is manufactured based on high-quality materials and is processed by special techniques. It has good corrosion resistance and small contact resistance with active materials to play a good discharge role. Compact in structure, it is easy to assemble and disassemble.Lithium Battery produced by GSL ENERGY are of safety, good design, easy installation, and wide applications. In the practical application, they effectively guarantee the stable operation of the power system as well as reduce the operating cost of the system. They are favored by many customers with high economic value.GSL ENERGY's Lithium Battery has better quality than other products in the industry, which is specifically shown in the following aspects.
1. powerwall battery is manufactured based on advanced technology. Unique in structural design, it can effectively prevent electrolyte splashing in the battery to make it reliable in safety.
2. tesla powerwall is manufactured based on unique formula and superior materials. It has good corrosion resistance and low self-discharge rate. Moreover, it is a green and high-quality product that does not contain harmful substances.
3. powerwall 2 is manufactured based on superior materials. It has good corrosion resistance, heat resistance, explosion-proof and sealing performance. By virtue of built-in battery pack, it has large capacity, high power, and excellent charge and discharge performance.
4. With continuous improvement, the product is believed to have greater sales growth in the future. Being environmentally friendly, GSL Li-Ion Battery will not destroy the ecological environment
PRODUCT PARAMETER
GSL ENERGY
| Products type | MODEL : GS5000 | Battery pack Discharge Current (Max.) | 150A |
| Cell Technology | Lifepo4 | Efficiency | 98% |
| Battery Pack Capacity (Wh) | 5120 | Depth of Discharge | 100% |
| Battery pack Voltage (Vdc) | 51.2 | Dimension (L*W*H, mm) | 650*480*190 |
| Battery pack Capacity (AH) | 100 | Communication | Option of CANBUS OR RS485, SMbus |
| Battery pack Cell Quantity in Series (pcs) | 16S | Protection Class | IP54 |
| Battery pack Charge Voltage (Vdc) | 58.4 | Weight | 54KG |
| Battery System Charge Current (Standard) | 10A | Operation Life | 10+ years |
| Battery pack Charge Current (Normal) | 20A | Operation Cycle Life | Over 4000 times |
| Battery pack Charge Current (Max.) | 50A | Operation Temperature | 0-50℃ |
| Battery pack Discharge lower-Voltage (Vdc) | 46V | Storage Temperature | minus 20 -- 60 ℃ |
| Battery System Discharge Current (Standard) | 20A | Products certificates | TÜV (IEC62619), CE |
| Battery pack Discharge Current (Normal) | 50A | Transfer Certificates | UN38.3 , MSDS |
PRODUCTS DISPLAY
48V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.
PRODUCT ADVANTAGE
1.High integrated with less installation space.
2.Long life cycle, >3000 times at 80% DOD.
3.Without heavy metals and environment friendly.
4.Maintenance free, no memory effect.
5.Internal BMS with full protection, high voltage protection with higher reliability.
APPLICATION
Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
PACKING
Good Quality Packs
VS
Low Quality Packs
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
Company Features
1. GSL ENERGY has been devoted into manufacturing powerwall battery for years.
2. Professional technicians and advanced equipment guarantee the magnificent quality of tesla powerwall.
3. GSL ENERGY is determined to dedicating itself to a cause that it will become a competitive brand among powerwall 2 industry. Ask online!
