Good Quality Packs
batteries lithium car battery baselin for car GSL ENERGY
Battery Type:
Lithium ion phosphate Battery
Brand:
GSL ENERGY
Model No:
GSL-KS20
Battery combination:
4S6P 26650 3.2V 3200mAh
Rated voltage:
12.8
Capacity:
20Ah
Size ( mm) / Size ( inch) L*W*H:
181*76*167/ 7.1*3.0*6.6
Weight:
2.5 kgs/ 6.28 lbs
Application:
AGV, Robots, Solar UPS, Solar street led lights, golf carts, Marine UPS.
Package:
UNCarton
Payment terms:
T/T , L/C
Delivery time:
With 20 days after deposit
Product Details
To better learn about OEM Lithium Ion Battery, GSL ENERGY will provide detailed pictures and detailed information in the following section for your reference. OEM Lithium Ion Battery is equipped with a large-capacity battery, which can be used for a long time. In addition, it is guaranteed to be high-quality by several tests.
Enterprise Strength
- GSL ENERGY is committed to providing customers with thoughtful, comprehensive and diversified services. And we strive to gain mutual benefit by cooperating with customers.
1. lithium car battery is scientific in design and simple in structure and is easy to assemble and disassemble.
2. Comparing with the existing lifepo4 100ah 12v , the proposed lithium car battery has many advantages, such asboat battery .
3. lithium car battery is manufactured based on advanced technology. Besides, it is charged three times and discharged twice to activate the battery before being shipped out of the factory. The balance, consistency and stability of the battery can be ensured.
PRODUCT PARAMETER
GSL ENERGY
| Products type | MODEL : KS20 | Battery pack Discharge Current (Max.) | 40A |
| Cell Technology | Lifepo4 | Efficiency | 98% |
| Battery Pack Capacity (Wh) | 256 | Depth of Discharge | 100% |
| Battery pack Voltage (Vdc) | 12.8 | Dimension (L*W*H, mm) | 181*76*167 |
| Battery pack Capacity (AH) | 20 | Communication | Option of CANBUS OR RS485, SMbus |
| Battery pack Cell Quantity in Series (pcs) | 4S | Protection Class | IP54 |
| Battery pack Charge Voltage (Vdc) | 14.6 | Weight | 2.5KG |
| Battery System Charge Current (Standard) | 5A | Operation Life | 10+ years |
| Battery pack Charge Current (Normal) | 10A | Operation Cycle Life | Over 4000 times |
| Battery pack Charge Current (Max.) | 20A | Operation Temperature | 0-50℃ |
| Battery pack Discharge lower-Voltage (Vdc) | 10V | Storage Temperature | minus 20 -- 60 ℃ |
| Battery System Discharge Current (Standard) | 10A | Products certificates | TÜV (IEC62619), CE |
| Battery pack Discharge Current (Normal) | 20A | Transfer Certificates | UN38.3 , MSDS |
PRODUCTS DISPLAY
12V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.
PRODUCT ADVANTAGE
1.High integrated with less installation space.
2.Long life cycle, >3000 times at 80% DOD.
3.Without heavy metals and environment friendly.
4.Maintenance free, no memory effect.
5.Internal BMS with full protection, high voltage protection with higher reliability.
APPLICATION
Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
PACKING
Good Quality Packs
VS
Low Quality Packs
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
Company Features
1. As a top manufacturer for lithium car battery , GSL GROUP Limited is devoted to developing better products.
2. GSL GROUP Limited has a group of designers and skilled manufacturing staff.
3. lifepo4 100ah 12v is the cardinal service principle of GSL GROUP Limited. Inquire now! boat battery is eternal tenet of an GSL GROUP Limited. Inquire now! GSL GROUP Limited insists on taking 12v lithium ion battery deep cycle as the direction of business development. Inquire now!
