GSL ENERGY telecom battery supplier for home
Battery Type:
Lithium ion phosphate Battery
Brand:
GSL ENERGY
Model No:
GSL48200-5U
Rated voltage:
48
Capacity:
200Ah
Size ( mm) / Size ( inch) L*W*H:
442*650*220/17.40*25.59*8.66
Weight:
87kgs/ 191.80 lbs
Application:
Solar off grid backup system, Solar Hybrid inverter UPS, Telecom UPS
Package:
Carton Box
Payment terms:
T/T
Delivery time:
With 20 days after deposit
Enterprise Strength
- GSL ENERGY constantly improves product quality and service system depending on technical advantages. Now we have a nationwide marketing service network.
Product Comparison
Lithium Ion Battery is reasonable in structure and exquisite in shape. It undergoes the tests of relevant departments and meets the national quality standards. Moreover, it is easy to assemble and disassemble.GSL ENERGY's Lithium Ion Battery has been further improved based on advanced technology, as reflected in the following aspects.
1. Raw materials of telecom battery meet the EU safety and environmental protection standards.
2. Multiple applications for telecom battery are available.
3. [企业简称] has strong technical force, rich production experience and advanced production equipment. Besides, we carry out the production based on advanced technology. All this ensures powerful performance and superior quality of telecom battery .
PRODUCT PARAMETER
GSL ENERGY
| BASICPARAMETERS | GSL4850-2U | GSL48100-5U | GSL48200-5U |
| Nominal Voltage(V) | 48 | 48 | 48 |
| Nominal Capacity(Wh) | 2400 | 4800 | 9600 |
| Dimension (mm) | 442*480*88 | 442*480*220 | 442*650*220 |
| Weight (Kg) | 23 | 48 | 87 |
| Discharge Voltage (V) | 45~54 | 45~54 | 45~54 |
| Charge Voltage (V) | 52.5~54 | 52.5~54 | 52.5~54 |
| Max Discharge Current (A) | 50 | 100 | 125 |
| Max Charge Current (A) | 50 | 100 | 125 |
| Communication | RS232,RS485,CAN | RS232,RS485,CAN | RS232,RS485,CAN |
| Charging Temperature | 0℃~50℃ | 0℃~50℃ | 0℃~50℃ |
| Discharging Temperature | -10℃~50℃ | -10℃~50℃ | -10℃~50℃ |
| Shelf Temperature | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ |
| Certification | IEC / CE / UN38.3 | IEC / CE / UN38.3 | IEC / CE / UN38.3 |
| Design life | 10+Years（25℃/77℉） | 10+Years（25℃/77℉） | 10+Years（25℃/77℉） |
| Cycle Life | >4500 ( 90% DoD) | >4500 ( 90% DoD) | >4500 ( 90% DoD) |
PRODUCTS DISPLAY
Product Performance
Vertical industry integration ensures more than 6000 cycles with 90% DoD.
Compact and fashionable design fits in your sweet home environment.
Deliver up to 5KW with single module (2.4KWh).
Modular design gives the end customers the power of choice of capacity.
Compatible with most of the available Hybrid inverters.
Simple buckle fixing minimize the installation time and cost.
Safety Cert.TüV CE UN38.3 IEC.
PRODUCT ADVANTAGE
You can optionally add mounting brackets GSL4850-2U to this product for a stable base, and to allow easy-stacking of multiple up to 10pcs at max.
APPLICATION
Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
PACKING
Good Quality Packs
VS
Low Quality Packs
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
Company Features
1. Since its establishment, GSL GROUP Limited has been a competitive manufacturer of telecom battery backup systems . We have earned a good reputation in the world.
2. GSL ENERGY pays attention to the application of battery bank in telecom tower technology.
3. There are clear goals for GSL ENERGY to be a most competitive company in the telecom battery industry. Get info! GSL GROUP Limited will continue to develop new products to enhance its reputation and visibility. Get info! GSL GROUP Limited aims to be the best manufacturer of solar street light with battery backup in the international market. Get info! GSL GROUP Limited attaches great importance to quality and service for better development. Get info!
{{item.score}} Stars
{{item.pre}}%
{{item.nickname ? (item.nickname.slice(0, 2) + '*****') : item.source === 1 ? 'mall buyer' : '--'}}
{{item.comment_time}}
Review in the {{item.country}}
{{itemAttr.params_key}}: {{itemAttr.params_value}}
