GSL ENERGY solar energy storage system intelligent control fast delivery1

Company Advantages
1. Every detail of GSL ENERGY solar battery 48v is professionally handled by designers who have years of experience in architecture design. The product's surface, edges, and colors are exquisitely determined to match the room. GSL 12V lithium-ion battery is a new environmentally friendly backup power system
2. Being sanitary and having a nonporous surface, this product is a good helper for the housewives. It's no wonder that this product is becoming so popular. GSL batteries help maximize the performance of users' battery system
3. The product offers high stability. It is made of slip-proof materials that can enhance shoe or foot traction, which effectively prevents slipping. GSL Li-Ion battery offers high performance and deep cycle energy storage
4. The product is innocuous and safe to use. The treating agents used in it are all skin safe and contain no harmful substances. The battery case of GSL Li-Ion battery is made from a Non-Conductive ABS plastic
5. The product has a smooth surface. In the polishing stage, the sand holes, air blisters, pocking mark, burrs, or black spots are all eliminated. Being environmentally friendly, GSL Li-Ion Battery will not destroy the ecological environment

Technology parameter sheet
Model		SHS-1200	SHS-2400	SHS-4800
Battery rated voltage		12.8VDC	25.6VDC	48VDC
Battery Type		Lifepo4(10 years)	Lifepo4	Lifepo4 Battery
Battery Capacity		100Ah	100Ah	100Ah
Inverter	Rated power	1000W	1500W	4000W
	Input voltage range	145-275VAC	145-275VAC	145-275VAC
	Input frequency	45-65Hz	45-65Hz	45-65Hz
	Output voltage	220VAC	220VAC	220VAC
	Output frequency	50/60Hz	50/60Hz	50/60Hz
	Output wave	Pure Sine Wave	Pure Sine Wave	Pure Sine Wave
	Specification of built-in battery		1*100AH/25.6V	1*100AH/48V
	Charge current	10A	10A	30A
MPPT Solar input	MPPT Voltage Range	15V-150VDC	30V-150VDC	60V-150VDC
	PV Power	400W	1200W	2900W
	Rated charge current	30A(Max)	50A(Max)	60A(Max)
	MPPT efficiency	≥99%	≥99%	≥99%
	Floating charge voltage	14.4VDC	28.8VDC	54VDC
DC output	Low voltage recovery voltage	13.4VDC	26.8VDC	50.2VDC
	Low voltage protection voltage	11.4VDC	22.8VDC	42.7VDC
	5VDC USB output	2units/MAX 2A	2units/MAX 2A	2units/MAX 2A
	12VDC output ports	2units/MAX 2A	2units/MAX 2A	2units/MAX 2A
Heat dissipation/Cooling		Temperature control by intelligent exhaust fan	Temperature control by intelligent exhaust fan	Temperature control by intelligent exhaust fan
Operating ambient temperature		-20 - +50℃	-20 - +50℃	-20 - +50℃
Storage ambient temperature		-25 - +55℃	-25 - +55℃	-25 - +55℃
Operating/Storage ambient		0-90% No condensation	0-90% No condensation	0-90% No condensation
External size:W*D*H(mm)		412*274*507	575*326*600	510*356*659
Package size:W*D*H(mm)		512*375*616	675*427*776	605*455*850
Weight (kg)		31	54	83

Product Performance

1.  This is a multi-function inverter/charger/solar system.

2.  Combining functions of inverter, solar charger and battery to offer uninterruptible power support with portable size.

3.  LCD display, configure input voltage range for home appliances and personal computers, configure battery charging current based on applications, configure AC/Solar Charge priority.

4.  Compatible to mains voltage or generator power, auto restart while AC is recovering.

5.  Users can flexibly match battery capacity, standard battery packages or external batteries.

6.  It combines a wide PV input range MPPT controller, can convert solar energy from PV to loads directly.

7.  Integrated design, Easy transportion and installation.

8.  Overload/Over temperature/short circuit protection.

9.  Our product are CE ,ROHS, ISO, FC approved, meeting various certification requirements for different countries.

◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE/ROSH/UL/VDE/MSDS/UN38.3,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.

Company Features
1. GSL GROUP Limited keeps stable and healthy development for many years. GSL ENERGY's factory has the independent research and development capability.
2. GSL GROUP Limited is a company that focuses on the quality of solar energy storage system .
3. GSL GROUP Limited has strong technical force and complete testing methods. Our company bears social responsibilities. We always attempt to recycle and reuse by-products or convert them back into valuable energy when recycling isn't feasible.
