Good Quality Packs
Products type | MODEL : GSL48120 | Battery pack Discharge Current (Max.) | 250A |
Cell Technology | NCM Lithium | Efficiency | 98% |
Battery Pack Capacity (Wh) | 6144 | Depth of Discharge | 100% |
Battery pack Voltage (Vdc) | 51.2 | Dimension (L*W*H, mm) | 660*330*230 |
Battery pack Capacity (AH) | 100 | Communication | Option of CANBUS OR RS485, SMbus |
Battery pack Cell Quantity in Series (pcs) | 14S | Protection Class | IP54 |
Battery pack Charge Voltage (Vdc) | 58.4 | Weight | 58.5KG |
Battery System Charge Current (Standard) | 10A | Operation Life | 10+ years |
Battery pack Charge Current (Normal) | 20A | Operation Cycle Life | Over 4000 times |
Battery pack Charge Current (Max.) | 50A | Operation Temperature | 0-50℃ |
Battery pack Discharge lower-Voltage (Vdc) | 46V | Storage Temperature | minus 20 -- 60 ℃ |
Battery System Discharge Current (Standard) | 20A | Products certificates | TÜV (IEC62619), CE |
Battery pack Discharge Current (Normal) | 150A | Transfer Certificates | UN38.3 , MSDS |
PRODUCTS DISPLAY
48V lithium ion battery is new environmentally friendly backup power system focus on short-time and high-rate discharge scenarios.The environmentally friendly lithium ion battery configured with high-performance BMS, has a wide range of performance and application advantages compared with conventional battery.
PRODUCT ADVANTAGE
1.High integrated with less installation space.
2.Long life cycle, >3000 times at 80% DOD.
3.Without heavy metals and environment friendly.
4.Maintenance free, no memory effect.
5.Internal BMS with full protection, high voltage protection with higher reliability.
APPLICATION
Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
--LED Backup / Engine Starting Battery,etc.
PACKING
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
WHY CHOOSE US
◆ Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
◆ Fresh battery-- All battery is fresh Production.
3.2v 400ah lifepo4 battery for solar power energy storage system
Item | Specification | Remark | ||
Rated capacity | 60Ah | 0.2C rate discharge capacity | ||
Minimum capacity | 60Ah | |||
Internal impedance | ≤1.2mΩ |
| ||
Nominal voltage | 3.2V |
| ||
weight | 2.0±0.1KG |
| ||
Standard discharge conditions | Constant current | 30A |
| |
End-of-charge voltage | 2.8V |
| ||
Standard charge method | Constant current | 15A |
| |
Charge voltage | 3.55V |
| ||
Fast charge method | Constant current | 60A |
| |
Charge voltage | 3.55V |
| ||
Max continuous discharge current | 180A |
| ||
Cycle life | 3000 cycles | 80% DOD | ||
Operating temperature |
Charging ambient temperature | 0~45°C |
| |
Discharging ambient temperature | -25~65°C |
| ||
Storage temperature | 0~45°C |
| ||
Appearance | Without break, distortion, contamination, leakage. |
|
Many kinds of model for your choice:
Applications of lithium iron phosphate
1. Power Battery
electric bicycles electric motorcycle
electric tricycle electric cars (hybrid and pure electric)
electric bus / minibus (electric and hybrid)
electric vehicles (electric golf carts, electric sightseeing cars, electric engineering vehicles, electric sweeper, electric forklifts, police patrol cars, electric cars and other balance)
Electric Boat
2. Energy storage power
solar / wind power energy storage system
battery power peaking, mining equipment and power
UPS mobile communication base station power (48V 100 --- 500AH)
PV off-grid power plants and network storage systems
3. Lighting
solar lawn lamp
Emergency Light 4.LED light power
solar wind and solar street light
4. Starting power
Power cars, motorcycles, railway locomotives, electric locomotives, passenger cars, such as the start
5. Power Tools
An electric mower, electric drill, fishing, etc.
electric model 3 electric robot
6.Military, aerospace power
